Cotek SP1000-224 1000 Watt 224 Volt Pure Sine Inverter

accessory (optional)

Remote Control: CR-8 / CR-16A; Transfer Switch: TR-40

ac regulation

┬▒3%

ac voltage

200 / 220 / 230 / 240VAC

brand

Cotek

dc input reverse polarity

By fuse

dc voltage

24VDC

dimensions

7.87"W x 3.27"H x 14.65"D

dry contact terminal

By relay

e-mark

Certified CISPR 25 ISO 7637-2

efficiency

(Max): 94%

emc standards

Certified EN 55022 class B; EN 55024 EN 61000-3-2, -3-3 EN 61000-4-2, 3, 4, 5, 6, 8, 11

frequency

50/60 Hz -/+5%

input

21.0 ┬▒0.5VDC (Under - Voltage Protection)

input over - voltage recovery

29.0 ┬▒0.5VDC

input under - voltage recovery

25.0 ┬▒0.5VDC

input voltage

24 Volts

input voltage range

21 - 33 Volts DC

led indicator

Input voltage level, output load level and faulty status

maximum output current

>1000VA~1150VA (100%~115%)

maximum power output

(1 min): >1000VA-1150VA (100%-115%)

no load current

Γëñ0.8A@24VDC

operating temperature

-4 to 104 degrees F (-20 to 40 degrees C)

output overload

Shutdown output voltage, restart to recover

output short

Shutdown output voltage, restart to recover

output voltage

220 Volts

output waveform

Pure Sine Wave

over temperature

Heat sink temperature over 80┬░C ┬▒5┬░C

power saving mode

<0.05A@24VDC

rated power

1000 VA

regulation

-/+3% AC

remote control terminal

6-port green terminal

safety standards

Certified EN 60950-1

storage temp.

-30┬░C ~ +70┬░C

storage temp. & humidity

10 ~ 95% RH

surge power (max.3 sec)

<1750VA

voltage range

21.0 ~ 33.0VDC

wattage

1000 Watts

waveform

Pure Sine Wave

weight

7.2 lbs
