Description
This 500 Amp magnetic latching remote battery switch solenoid provides high amperage switching under load, manually or from remote locations.
- Manual override knob provides an added level of safety allowing control with or without power and offering LOCKED OFF capability for servicing
- LED output to remotely indicate switch state - requires optional LED
- 3∕ 8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance
- 7∕ 8" (22 mm) stud length accepts multiple cable terminals
- Label recesses for circuit identification
- Silver alloy contacts provide high reliability for switching live loads
- Auto Releasing ML-Series Remote Battery Switch with SPST Switching Provides 500A switching and features of current ML Remote Battery Switches, but can be controlled with SPST or SPDT switch for applications where a normally open relay is desired
Warning: Product may contain materials cautioned by California Proposition 65
Specifications
Amp Operating Current | 8mA when OFF / 13mA when ON |
Amperage Operating Current | when changing state: <4A (40 ms) |
Cable Size | to Meet Ratings: 2x (4/0) |
Coil Function | Auto releasing |
Continuous Rating | 500A |
Control Circuit Connection | Tinned Wire |
Control Circuit Voltage | 20.2 to 32.9V DC |
Cranking Rating (30 sec) | 1450A DC |
Intermittent Rating | 700A (5 min) |
Live Current Switching | 300A @ 12V DC 10,000 Cycles |
Manual Control | Yes |
Master Control Capability | Yes |
Max. Operating Temperature | 60° C |
Mechanical Endurance | 100,000 Cycles |
Min. Operating Temperature | -10° C |
Mounting | #10 |
Nominal Voltage | 24V DC |
Switching Cycles | 100000 |
Terminal Ring | Diameter Clearance: 1.18in (29.97 mm) |
Terminal Stud Length | 0.875in (22.23 mm) |
Terminal Stud Size | 3/8" - 16 (M10) |
Terminal Stud Torque | 140 in-lb (15.82 Nm) |
