Power Products Blue Sea Systems 7475-BSS C-Series Flat Rocker Circuit Breaker Double Pole 150A

actuator

Flat Rocker

amperage

150A DC

circuit breaker

Magnetic Hydraulic - trip free

interrupt capacity

5000A @ 48V DC

maximum operating temperature

85┬░ C

maximum voltage

120V AC, 240V AC, 48V DC

minimum operating temperature

-40┬░ C

mounting screws

6-32 Stainless Steel

mounting screw torque

6 in-lb (0.68 Nm)

poles

2

switching cycles

10000

terminal stud

1/4-20 Tin-Plated Brass

terminal stud torque

35 in-lb (3.95 Nm)

weight

0.64 Ibs.
