WFCO WF-5118 1800 Watt Power Inverter

WFCOSKU: WF-5118

Price:
Sale price£751.00
Stock:
Only 1 unit left
Free Shipping* (Some exclusions apply)TRUE

Description

25% Off With Code: INVERTER25
While supplies last, terms and conditions apply.




The WFCO WF-5118 is a high-performance 1800 Watt power inverter designed with robust safeguards, including overload, over-temperature, short-circuit, and reverse polarity protection. Its efficient cooling fan adjusts its operation based on the load, optimizing performance.

Equipped with an automatic transfer switch, pure sine wave output, and advanced filtering for sensitive electronics, the WF-5118 ensures reliable power delivery. LED status indicators provide real-time information on battery charge, inverter load levels, and low battery warnings. Additionally, its remote control system offers convenient access to the same display menu as the unit itself.

Protection Features:

  • AC Output Power
  • Internal Cooling
  • Over Temperature
  • Overload
  • Reverse Polarity (Fuse)
  • Short Circuit

Status Indicator Lights:

  • Green – AC normal
  • Amber – On battery
  • Red – Overload
  • Fault Two LED Bars (w/ 4 LEDs) – Battery and Load Level

Warning: Product may contain materials cautioned by California Proposition 65

Specifications

AC Output Power Protected by 20A/120VAC Circuit Breaker
AC Voltage Regulation +/- 3% from no load to full load under battery range
Certifications cUL458, FCC Class B compliant
DC Connection #2/0 AWG wires required and with 250Adc in-line fuse
DC Input Voltage 12V DC
Dimensions 16.2 L x 10.8 W x 6.65 H (Inches)
Efficiency (Full Load) >80%
Input Voltage Range 10-15 VDC
Input Voltage/Hz 120 VAC, 60 Hz
Internal Cooling DC brushless forced fans
Output Waveform Pure Sine Wave (THD <3%)
Over Temperature Protection System Shut Down
Overload Protection Current limiting & shutdown
Remote Control Panel Yes
Reverse Polarity Protection Fuse Protected
Transfer Switch Automatically transfer to battery power whenever AC power fails DPDT relay with 20A/120Vac contact rating
Transfer Time <50 milliseconds
Watts 1.8kW
Weight 20 lbs
