Description
ICM325HN Single-Phase Head Pressure Control (120-480 VAC)
Head pressure, fan speed control, temperature responsive, RoHS compliant, 120/208/240/480 Vac controlled, requires 18-30Vac input
Integral heat pump bypass circuitry allows electronic bypass of speed control during heat pump operation
Features: Hard start, low temperature cutoff, high temperature bypass
Controls up to 3 refrigerant circuits
Varies motor speed
Kit includes 70-100°F probe
ICM325HNC requires 18-30Vac input, ICM326HNC, ICM327HNC have internal transforms; operate from controlled voltage
Output current - Triac maximum: 10 amps
minimum: 100 mA
ICM32*HN* models are RoHS compliant (lead free)
Input Control: 18-30 Vac
Voltage Controlled: 120/208/240/480
