Description
The PD1610A is a battery separator/isolator is a 200 Amp device from Cole Hersee. Similar to Sure Power's battery separator, it's designed for use with alternators up to 200 amps. This versatile component prevents auxiliary battery loads from draining the starting battery. Different from traditional isolators, it accommodates all alternator types, offering a more compact, lightweight, and heat-efficient solution with no diode efficiency losses.
Features:
- Reverse battery protection
- Thermally controlled fan speed
- Unit can be monitored by remote control
- Auto Restart after power interrupt
- Easy AC hardwire hookup
- Remote included
- DC lug connection
- Pure Sine Wave
Warning: Product may contain materials cautioned by California Proposition 65
Specifications
| AC Connections | Vertical push-in connections only (no GFCI) |
| AC Knockouts | Removable by hand |
| AC Output Voltage | 120 Volts AC +/-2% |
| AC Pass-Through Current | 15A (no breaker required) |
| Auto-Restart | 20A (no breaker required) |
| Built-In Transfer Switch | 20 Amps @ 95-135 VAC |
| DC Connections | DC Lugs (no expensive ring terminal required) |
| DC Input Current | Approx. 100 amps at full power output |
| Display Data | DC Volts In, AC Volts Out, AC Power Out, Error Codes |
| Display Indicators | Low Bat Warning, Fault, Shore, Power |
| Display Sleep Mode | After 30 seconds, Display turns off, Power indicator remains on |
| Fan Control | Variable Speed >500 watt loads |
| Optimum Efficiency | >90% |
| Pure Sine Wave | 1000 Watt |
| Remote Control Location | Up to 50’ wired connection |
| Remote Control Panel | Full control (same as on-board control) |
| RV-C Compatible | Yes |
| Surge Power (peak) | 2000 Watt |
| Unit dimensions | 11.2 x 6.7 x 4.0 |
| Unit weight | 7 lbs |
