Description
Introducing the Triple Battery Bank Management Panel
- Isolates the Engine circuit from the House circuit
- Allows emergency cross connect between isolated battery banks
- Protects electronics from sags and spikes caused by engine cranking
California Proposition 65: WARNING Cancer. www.P65Warnings.ca.gov
Specifications
| Continuous Rating | 350A |
| Cranking Rating 1 min | 750A |
| Cranking Rating 10 sec | 1000A |
| Depth | 3.50in (88.9 mm) |
| Height | 8.00in (203.2 mm) |
| Intermittent Rating | 525A (5 min) |
| Maximum Voltage | 32V DC |
| Nominal Voltage | 12V DC / 24V DC |
| Positions | 11 |
| Weight | 4.42lb (2 kg) |
| Width | 10.50in (266.7 mm) |
